Eton ETU-VAG180 - 18cm mid-bass driver

Eton ETU-VAG180 - 18cm Mid-bass driver

The ETON UG VAG 180 speaker is compatible with the VW Arteon, Atlas, Beetle, Passat B8, Tiguan I and II, Touran, the Seat Alhambra II and Tarraco, or the Skoda Octavia II, Superb II and Yeti. The 18 cm (7") long-throw mid-bass driver offers top performance at an unbeatable price/performance ratio and is easy to retrofit: The speaker is 100% plug & play and integrates perfectly into VAG models. Connection is via the original connector. The newly developed diaphragm enables a significant performance boost, especially in bass: The specially manufactured, rib-reinforced fiberglass-paper diaphragm is particularly light and rigid. This makes it the ideal basis for a high-quality speaker and, despite its relatively small diaphragm area, ensures a powerful, mature sound: Bass is reproduced with punch, consistent volume, and the necessary dynamics; voices sound full, natural, and nuanced. A very powerful ferrite magnet with a large pole piece vent drives the diaphragm with impressive force. Thanks to its 3-ohm impedance, the UG VAG 180 is particularly efficient – even when used with factory radios/head units without an additional amplifier. 89 dB sensitivity and 100 W music power handling speak for themselves. The fiberglass-reinforced polyamide basket with integrated sealing flange is low-resonance, torsionally rigid, and offers a perfect fit. Thanks to the VAG-specific 6-point mounting system and the characteristic VAG connection terminal, the UG VAG 180 is easy to install. The set includes optional low-pass crossovers for optimal sound tuning within the vehicle. The UG VAG 180 is ideal for combination with the ETON UG VAG 150 (as a rear system) and the UG VAG 25. Tweeter Set.

Key Features

• 18 cm (7") Long-Throw Mid-Woofer for VW Models
• Newly Developed Rib-Stiffened Paper-Fiberglass Cone
• Fiberglass-Reinforced Polyamide Basket with Integrated Sealing Flange, VAG-Specific 6-Point Mounting, and VAG-Specific Connection Terminal
• Powerful Ferrite Magnet with Large Pole Bore
• 3 Ohm Impedance for Particularly High Efficiency
• Engineered in Germany
• Scope of delivery: 2 x mid-bass drivers, 2 x low-pass cable crossovers, 2 x ETON logo aluminum adhesive plates, blind rivets for mounting

Technical data

• Music power handling: 100 W
• Nominal power handling: 70 W RMS
• Impedance: 3 ohms
• Sensitivity: 89 dB
• Recommended crossover frequency HPF: ~ 50 - 80 Hz / 6 or 12 dB
• Recommended crossover frequency LPF: ~ 2.5 kHz - 4 kHz / 6 or 12 dB
