RL4-MIB front/rear view camera input NTSC for VAG MIB Standard/High

RL4-MIB

The video interface allows you to feed a rearview camera, an automatic front camera, and any two video sources (e.g., USB player, DVB-T2 tuner, etc.) into the vehicle manufacturer's factory infotainment system.

Product Features

• Video feeder for factory infotainment systems
• 1 CVBS rearview camera video input
• 1 CVBS front camera video input
• 2 CVBS video inputs for aftermarket devices (e.g., USB player, DVB-T2 tuner, etc.)
• Automatic switching to the rearview camera input when reverse gear is engaged
• Automatic front camera switching after reverse gear for 10/15/20 seconds
• Guide lines for rear view camera can be activated (not available for all vehicles)
• Image in-motion while driving (ONLY for input video)
• Video inputs compatible with NTSC and PAL

Compatibility

• AUDI with MMI Navigation Plus with MMI Touch 7, 8 or 8.3 inch MIB/MIB II main unit
• Audi A3 (8V) from 05/2012 - 02/2020,
• Audi A4 (8W) from 08/2015 to 04/2019,
• Audi A5 (F5) from 07/2016 to 09/2019,
• Audi A6 (4G) from 09/2014 to 05/2018,
• Audi A7 (4G) from 05/2014 to 01/2018,
• Audi Q2 (GA) from 09/2016,
• Audi Q5 (FY) from 01/2017 - 08/2020,
• Audi Q7 (4M) from 03/2015 to 08/2019

AUDI with MMI navigation 7 inch MIB Std Nav/MIB Std Plus MMI Radio Plus 5.8 or 7 inch, MIB Entry Plus/MIB Std

• Audi A3 (8V) from 05/2012 - 02/2020,
• Audi A4 (8W) from 08/2015 to 04/2019,
• Audi A5 (F5) from 07/2016 to 09/2019,
• Audi Q2 (GA) from 09/2016,
• Audi Q5 (FY) from 01/2017,
• Audi Q7 (4M) from 03/2015 to 08/2019

Bentley Bentayga with MIB 8 inch monitor

PORSCHE with PCM 4.0

• Porsche 911 (991.2) from 2016 to 2019,
• Porsche Boxster (982). 2016,
• Porsche Cayenne E2 (92A) from 2016 to 2017,
• Porsche Cayman (982) from 2016,
• Porsche Macan from 2015 to 2018

SEAT with MIB/MIB2 High/Standard, Navigation System Plus or Media System Plus/Easy Connect, 6.5 inch or 8 inch monitor

• Seat Arona (KJ7) from 2017,
• Seat Ateca (KH7) from 04/2016,
• Seat Ibiza (KJ) from 06/2017,
• Seat Leon3 (5F) from 2013 - 2019,
• Seat Toledo4 (KG) from 2016

SKODA with MIB/MIB2 High/Columbus and Standard/Bolero/Amundsen, 5.8-inch, 6.5-inch, or 8-inch monitor. Not compatible: 2018 9.2 inch monitor.

• Skoda Fabia3 (NJ) from 10/2014 - 08/2021,
• Skoda Kamiq (NW4) from 06/2019
• Skoda Karoq (NU7) from 2018,
• Skoda Kodiaq (NS7) from 2017,
• Skoda Octavia3 (5E) from 2012,
• Skoda Rapid (NH1) from 2016,
• Skoda Superb3 (3V) from 2015

VW with MIB/MIB2, High/Discover Pro and Standard/Composition Media, 5.8 inches, 6.5 inches or 8 inch monitor. Not compatible: 2018 9.2 inch monitor.

• VW Arteon (3H) from 2018,
• VW Crafter (SZ/SY) from 2017,
• VW Golf7 (5Q) from 2012 - 2019,
• VW Golf7 Sportsvan (AM1) from 2014 - 2020,
• VW Passat (B8) from 2016,
• VW Polo5 (6C) from 2014 to 2017,
• VW Polo6 (AW1) from 2018,
• VW T-Cross (C1) from 04/2019,
• VW T-Roc (A11). 2018,
• VW Taigo (CS) from 09/2021
• VW Tiguan2 (AD1) from 2016,
• VW Touran (5T) from 2016
• VW Transporter T6.1 (6H) from 10/2019,

ATTENTION!

• Interface not suitable for Audi TT, Audi R8, and Lamborghini Huracan. The RL3-MIB-TT must be used here.
• In some vehicles, e.g., Polo, there may not be enough space behind the factory head unit for the straight HSD interface socket of the interface cable set. In this case, the optional cable CAB-HSD-MD035 is also required.

Connections

• Image input: 4-pin HSD
• Power and CAN bus: Plug & Play (Vehicle-Specific)
• Video Inputs (2x): RCA Jacks
• Rear View Camera Input: RCA Jack
• Front Camera Input: RCA Jack

Technical Specifications

• Operating Voltage: 12V DC (7~25V)
• Quiescent Current: 5mA
• Current Consumption: 210mA
• Video Input: 0.7~1V
• Video Input Formats: NTSC/PAL
• Operating Temperature: -40°C to +85°C

Video Box Dimensions: 117 x 25 x 104mm (W x H x D)
