Audio System LDS-NTG40-Mini - Smartphone integration Mercedes NTG4 (Quadlock)

LDS-NTG40-Mini

Plug & Play smartphone interface with full integration into the car's multimedia system. Check the compatibility list to see if we have a solution available for your car.

The image is displayed on the entire factory monitor, and the audio is fed in via the audio AUX input or Bluetooth A2DP input of your factory multimedia system. Before ordering, please check whether your factory multimedia system has an audio AUX input or supports Bluetooth A2DP.

Our smartphone interface is compatible with Apple CarPlay.®  and Android Auto, making it a smarter and safer way to use your smartphone in the car. Everything is operated via the vehicle's own buttons and controls. Of course, you can also use Siri.  and OK Google  Use voice control via the included microphone.
Everything you want to do with your smartphone while driving is possible with Apple CarPlay.®  and Android Auto can be used directly via the car's display. You can easily get directions, send and receive messages.
If your car has a factory-installed hands-free system, you can use our smartphone integration to operate it and make calls. While navigating, you can listen to your favorite music via Spotify or your favorite radio station via a radio app – all while keeping your focus on the road.
Simply connect your smartphone to the USB port in our system and you're good to go.

You can connect your Apple iPhone wirelessly via Wi-Fi for even greater convenience. Wireless Apple CarPlay®  This is possible from the Apple iPhone 5 onwards. Of course, "Wireless Google Android" is also supported if your Android smartphone has Android 11 and Android Auto 4.8 or higher and 5GHz Wi-Fi .

Features

• Interface for retrofitting Apple CarPlay® and for Android  car
• Operation via OEM buttons/touchpad from the vehicle
• Wireless Apple CarPlay® via included Wi-Fi antenna from iPhone 5 onwards
• Wired Apple CarPlay® via USB (turn off Wi-Fi on iPhone)
• Wired Android  car  via USB
• Android  MirrorLink function (mirroring the smartphone display)
• USB input for multimedia playback, software updates, or wired smartphone connection
• HDMI input (audio only via audio aux output)
• Video playback on Apple iOS is only possible via a USB cable.
• Supports RMVB, MOV, MKV, MP4, AVI, RM with up to 1080p HD resolution
• Pairing the smartphone is only necessary during the initial setup.
• Integrated audio DSP with equalizer for the audio output
• Analog audio output with 3 volt output voltage for sound playback (Audio AUX)
• Supports left- and right-hand drive vehicles
• "Apple Siri" and "OK Google" voice control via included microphone (no telephony)

APPS

• GPS navigation with Google Maps and Apple Maps, and much more.
• Music playback with Spotify, Apple Music, Amazon Prime and more

camera  functions

• Front camera input (AHD/CVBS)
• Input for reversing camera (AHD/CVBS)
• Support for parking distance control (PDC) systems
• Support for movable guide lines
• Supports 360° camera systems
• 12 volt output for powering the front camera
• 12-volt output for powering the rear camera

Vehicle compatibility

Before purchasing and installing, please check that the product is compatible with your car make, model year, and entertainment system. Your entertainment system must have an audio AUX input for sound playback. Incompatibility may result in damage.
Special feature: Mercedes S-Class W221 10/2005-05/2009 with NTG3 and other vehicles with UCI
With the "Universal Communication Interface (UCI)" (SA Code 518) equipment, the LDS-UCI-AUX35F adapter is also required for audio input.
Note:  Vehicles with dual-view monitors will  not  supported! (SA Code 867)

Smartphone compatibility

ATTENTION : Some manufacturers, such as Samsung, have their own Android-based operating system. Wireless use may not be possible with these devices.

"Wired" connection via USB cable
Before purchasing and installing, please check if our product is compatible with your smartphone.

• For Apple iOS: at least iPhone 5 or higher
• For Google Android: at least Android 5.0 (Lollipop), preferably Android 6.0 (Marshmallow) or higher.

"Wireless" connection - Wireless via WLAN
Before purchasing and installing, please check if our product is compatible with your smartphone.

• For Apple iOS: at least iPhone 5 or higher
• For Google Android: at least Android 11 and Android Auto 4.8 or higher, 5GHz Wi-Fi.

Technical data

• Operating voltage: 12VDC +/-10%
• Maximum current draw: 1.35A
• Standby current consumption: 2mA
• Current consumption when off: 0mA
• USB charging current: 1100mA
• Operating temperature: -25°C ~ +75°C
• Dimensions: 120x90x19mm

Approvals

E-approval number E57*10R06/00*0081
E-approval number E57*COP*0279

Installation instructions

This product is used in vehicles with a 12V battery. Do not install in vehicles with a different voltage. Never extend the HSD signal wires. This product consists of high-precision parts and should therefore not be subjected to strong impacts. Never open the housing. To protect driving safety and avoid traffic violations, never operate the product while driving. The optional reversing cameras are only visible when maneuvering. Always pay attention to your surroundings and never rely solely on the camera. All installation steps should only be performed by a qualified professional. During installation, the ignition must be switched off, and the product should only be connected to power after all wiring is complete. NEVER plug in or unplug the cables while the power is on to avoid damaging the monitor or the product. Route the cables so that they do not come into contact with metal edges. This can damage the wiring, which can lead to fires. Avoid any contact with hot surfaces when wiring the main unit. High temperatures can damage the wiring and cause short circuits, arcing, and fires. To avoid electric shock, damage, and fire caused by a short circuit, please DO NOT install the product in a humid environment. Upon receiving the product, please check that all components are present in the packaging. If anything is missing, inform the supplier/manufacturer. Start the engine before loading, check the interface to ensure the function is displayed, and check the key to ensure the vehicle interface is working correctly. Please provide feedback to the supplier/manufacturer if you have any questions. Please handle the disassembled vehicle parts carefully during installation and avoid scratching the instrument panel. Unused connector plugs must be insulated to prevent short circuits. Cable connections should be securely plugged in. Avoid interfering with control components such as the steering wheel, accelerator, and brake pedals.
