Audio System DSP 4.6-BT - 6-channel DSP and BT

DSP 4.6-BT

• DSP-SERIES 6-channel DSP and BT
• APP software adjustable via ANDROID-BT or iOS-BT
• 6-channel SIGMA DSP processor from ANALOG DEVICES with automatic
  UPDATE via WLAN
• 30 parametric EQs per channel
• 8 presets
• Up to 48 dB slope
• 6 DSP-controlled RCA outputs (5 volts)
• 4 RCA inputs (low level 0.5 to 4 volts)
• 4 Molex high-level inputs (up to 12 V) via BTL or SE signal detection with automatic switch-on
• 1 Remote output
• Frequency range: 10-24000 Hz
• Signal-to-noise ratio ADC: 107 dB and DAC: 112 dB
• Start/stop capable up to 6 volts/5 seconds
• Operating voltage 10-16 volts
• Operating temperature from -40°C to +85°C

Dimensions

• 180 x 160 x 45 mm
