Musway M6PRO - 6-channel class-D amplifier with 10-channel DSP

Musway M6PRO 6-CHANNEL CLASS D AMPLIFIER WITH 10-CHANNEL DSP

The M6PRO 6-channel DSP amplifier is aimed at true sound enthusiasts who don't want to install simple plug-and-play upgrades for factory systems, but prefer customized car audio systems with higher performance. Experienced professionals are happy to accept the additional wiring effort. It's worth noting that, despite a power increase of over 400 watts, the M6PRO version is barely larger than the M6 Plug+Play version. With compact dimensions of 16 x 25 cm, the more powerful Pro version remains virtually identical to the regular M6. As good as the regular M6 already is, the PRO version takes it to the next level. With an impressive 6 x 142 watts at 4 ohms and 6 x 249 watts at 2 ohms, it is the most powerful 6-channel DSP amplifier ever measured in the Car&Hifi test lab.

The PRO version also offers an enhanced feature set: A powerful 10-channel DSP with 4 processed RCA outputs for driving additional amplifiers has been implemented. The DSP chip used is the proven Analog Devices™ ADAU1452, combined with high-end signal converters from Burr-Brown™. Sound adjustments can be made instantly via a smartphone app or traditional PC software.

Features:

• High-level input with EPS® (Error Protection System)
• Start-stop capability, automatic power-on
• Burr-Brown converter (PCM3168A) and Analog Devices DSP (ADAU1452)
• Dual 64-bit, 295 MHz DSP technology, controllable via PC software or smartphone app
• Soft clipping (power attenuation) in 2 ohm operation
• Signal-to-noise ratio 100 dB
• Frequency response 10 Hz – 22.5 kHz (-3dB)
• THD 0.01% (1kHz, 4 ohms, 10W)
• External Bluetooth® USB dongles BTS, BTS-HD & BTA2 for audio streaming and app control (optional)
• DRC1 digital remote control with OLED display for controlling various DSP functions (optional)

Specifications:

• 6 x 120/200 watts RMS @ 4/2 ohms or
• 3 x 400 watts RMS @ 4 ohms bridged
• 6 x low-level inputs (RCA)
• 6 x high-level inputs with EPS®
• 2 x AUX inputs (RCA)
• 1 x optical input/stereo PCM
• 6 x amplified speaker outputs
• 4 x preamplifier outputs (RCA) (configurable via DSP)

Dimensions: 160 x 45 x 235 mm
