JL Audio XDM1000/1 - 1-Channel Monoblock Subwoofer Amplifier for Car and Marine

JL Audio XDM1000/1

Powerful, Compact, Incredible Value

Thanks to NexD technology, XDM amplifiers achieve an overall efficiency of over 80%. This results in lower energy consumption and thus protects your electrical system.

Technical Specifications

General

• Channels Monoblock/2/3/4/5/6/8
• Physical Dimensions (Height) 2.05" (52 mm)
• Dimensions (Width) Monoblock (300 W)/2-Channel: 6.85" (174 mm)
• Monoblock (600 W)/3/4-Channel: 8.52" (216 mm)
• 5 (700 W)/6-Channel: 10.23" (260 mm)
• Monoblock (1000 W)/5 (1000 W)/8-Channel: 14.73" (374 mm)
• Physical Dimensions (Depth) 7.09" (180 mm)

Warranty

• 3 Years
• Operating Voltage 11-14.5 VDC (12 V models)

Audio

• Amplifier Class Class D
• Rated Continuous Power (RMS) (14.4 V input at 4 ohms < 1% THD)
• Monoblock (1000 W): 600 W x 1

Rated Continuous Power (RMS) (14.4 V input at 2 ohms < 1% THD)

• Monoblock (1000 W): 1000 W x 1

Rated continuous power (RMS) (12.5 V input at 4 ohms <1% THD)

• Monoblock (1000 W): 500 W x 1

Rated continuous power (RMS) (12.5 V input at 2 ohms <1% THD)

• Monoblock (1000 W): 800 W x 1

• Signal-to-noise ratio, based on the highest rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog inputs monoblock (300 W): > 100 dB
• Monoblock (1000 W): > 83 dB
• Monoblock (1000 W): > 53 dB
• Monoblock (1000 W): > 1000/50 Hz
• Monoblock (1000 W): > 500/50 Hz
• Monoblock (600 W/1000 W): 7 Hz–500 Hz
• Input voltage range @ RCA inputs Monoblock (300 W/600 W/1000 W)/2/3/4-channel: 200 mV–4 V RMS
• Fuse rating Monoblock (300 W): 30 A
• Monoblock (1000 W)/5 (1000 W)/8-channel: 80 A
• Recommended fuse types AFS, AGU, or MaxiFuse™

Signal processing

• Filter mode(s): Channels 1 and 2 Monoblock (300 W/600 W/1000 W): Off or only Low-pass filter
• Filter slope(s): Channels 1 and 2 monoblock (300 W/600 W/1000 W): 12/24 dB/octave
• Filter frequency range: Channels 1 & 2 monoblock (300 W/600 W/1000 W): 50 Hz–500 Hz
• Filter mode(s): Channels 3 and 4 4/6-channel: Off, low-pass, or high-pass
• Filter frequency range: Subwoofer channel 3/5-channel (700 W/1000 W): 50 Hz–500 Hz
• Detented, calibrated filter frequency potentiometers
• Remote fill level control: Optional HD-RLC or MHD-RLC (water-resistant)
